TOLERANCES

STENCIL PRINTING

  • Minimum stencil size 650mm x 650mm
  • Maximum stencil size 850mm x 850mm
  • PCB minimum size = 80mm x 50mm
  • PCB maximum size = 610mm x 610mm

REFLOW OVENS

  • Temperature range 77°F (25°C) – 662°F (350°C)
  • Accuracy of temperature control ±1°F
  • Minimum/maximum board width 5cm to 45.7cm
  • Maximum conveyor speed 188cm/min

MIRTEC MV3 OMNI DESKTOP AOI

  • Minimum board size 50mm x 50mm
  • Maximum board size 450mm x 400mm

INSPECTION CAPABILITY

  • FHD – 47X zoom
  • HD – 40X zoom
  • Mantis Elite – 10X zoom

ABOUT

Nova is a full-service printed circuit board assembler located in Denver, Colorado.
